HOW TO INSTALL.

NOCO Lithium Powersport has terminals that can be mounted from the front, side, or top, and can be removed altogether depending on the application. A removable mounting block allows the battery to fit more applications. The threaded insert enables direct-mounting for additional simplicity and security. The modular mounting spacer can be stacked and attached to the NLP batteries to alter the BCI size enabling the battery to be safely and securely mounted. 

STEP 01

Remove original battery from vehicle following manufacturer’s guidelines.

STEP 02

Compare the height of original battery to NLP Lithium Powersport battery.

STEP 03

If the original battery dimensions is larger than NLP then use included spacers and foam to adjust the size to match the original battery as closely as possible.

STEP 04

Securely fasten the battery to the battery tray, making sure the power cables reach both terminals.

STEP 05

Using the included fastening hardware attach the Positive battery cable to the Positive battery terminal.

STEP 06

Then, attach the Negative battery cable to the Negative battery terminal.

STEP 07

If necessary, mount cables in an alternate position with NLP's alternate connection terminal options.

STEP 08

Be sure to fasten the bolts securely, but be careful not to over tighten.

POWERSPORT.

5 YEAR WARRANTY.

All NOCO Lithium Powersport batteries come with a limited 5 Year warranty. Register your product after purchasing to qualify for the applicable warranty.

REGISTER PRODUCT VIEW WARRANTY

NLP

FAQS

Specs & Features

Warranty & Support

Installation & Compatibility

Usage & Care

Which spacers should I use with NLP5?

The following table provides the battery fitment and the corresponding spacers and foam needed to achieve proper height, width and length for retrofit applications.

NLP5

BCI Sizes	Yuasa Sizes	Spacers
BTZ5S BTX4L-BS	YTZ5S-BS YTX4L-BS	None
BTX5L-BS BTZ7S	YTX5L-BS YTZ7S	(1) 20 mm
BTZ8V BTX7L-BS	YTZ8V YTX7L-BS	(1) 20 mm, (1) 24 mm

Which spacers should I use with NLP9?

The following table provides the battery fitment and the corresponding spacers and foam needed to achieve proper height, width and length for retrofit applications.

NLP9

BCI Sizes	Yuasa Sizes	East Penn	Spacers
BTX7A-BS	YTX7A-BS		None
BTX9-BS	YTX9		(1) 12.5 mm
BTR9-BS	YTX9-BS	ETX9	(1) 12.5 mm

Which spacers should I use with NLP14?

The following table provides the battery fitment and the corresponding spacers and foam needed to achieve proper height, width and length for retrofit applications.

NLP14

BCI Sizes	Yuasa Sizes	East Penn	Spacers
BTZ10S	YTZ10S		None
BT12A-BS	YT12A-BS		(1) 12.5 mm
BTZ12S BTZ14S	YTZ12S YTZ14S		(1) 17 mm
BTX12-BS	YTX12 YTX12-BS	ETX12	(1) 12.5 mm (1) 17 mm
BTX14 BT14B-4 BTX14-BS	YTX14 YTX14-BS YTX14H YTX14H-BS GYZ16H KMX14-BS	ETX14 ETX14L	(2) 25 mm
BTX16-BS BTX16-BS-1 BTX20CH-BS	YTX16-BS YTX16-BS-1 YTX20CH YTX20CH-BS		(1) 17 mm (2) 25 mm
B16A-AB	HYB16A-AB		(1) 12.5 mm (3) 25 mm

Which spacers should I use with NLP20?

The following table provides the battery fitment and the corresponding spacers and foam needed to achieve proper height, width and length for retrofit applications.

NLP20

BCI Sizes	Yuasa Sizes	East Penn	Spacers
BTX15L BTX15L-BS	YTX15L YTX15L-BS		None
BTX20L BTX20HL-BS BTX20L-BS BTZ20L	GYZ20L GYZ20HL YTX20HL YIX20HL YTX20L YTX20L-BS YTX20HL-BS	ETX20L	(1) 12 mm (1) 15 mm
B16L-B	YB16HL-A-CX YB16L-B SYB16L-B	ETX16 ETX16L	(1) 12 mm (1) 15 mm (2) 7.5 mm Foam
	YTX20HL-PW YIX20HL-BS YTX20HL-BS-PW		(3) 15 mm
B18L-A			(2) 15 mm (1) 7.5 mm Foam
B50-N18L-A3	Y50-N18L-A3		(2) 15 mm (4) 7.5 mm Foam
B16CL-B	YB16CL-B		(3) 15 mm (2) 7.5 mm Foam

Which spacers should I use with NLP30?

The following table provides the battery fitment and the corresponding spacers and foam needed to achieve proper height, width and length for retrofit applications.

NLP30

BCI Sizes	Yuasa Sizes	East Penn	Spacers
BTX30L-BS BTX30L	GYZ32HL YIX30L	ETX30L	None

What is the recharge time for NOCO Powersport batteries?

To recharge NOCO Powersport batteries, connect a compatible lithium-ion charger to the positive ( ) and negative (-) battery terminals. The recommended charging voltage is 14.6-volts. The product uses advanced lithium-ion technology that allows for the rapid charging of the internal lithium-ion cells.

This is a table of the charging times, based on 100% depth-of-discharge (DOD), using recommended NOCO Genius Smart Battery Chargers:

	GENIUS1	GENIUS2	GENIUS5	GENIUS10
NLP5	2 hours	1 hours	24 minutes	––
NLP9	3 hours	1.5 hours	36 minutes	––
NLP14	4 hours	2 hours	48 minutes	24 minutes
NLP20	7 hours	3.5 hours	1.4 hours	42 minutes
NLP30	8 hours	4 hours	1.6 hours	48 minutes

Compatible Products

Use the Lithium mode on any GENIUS charger to fully recharge an NLP battery in minutes.
