Videos
How to jump start using your NOCO Boost GB150
More Videos
GB150
HOW TO JUMP START.
ATTACH CLAMPS.
POWER ON.
START VEHICLE.
POWER OFF.
Or power off/on to reset.
GB150
LEDs
Power LED
Illuminates White when unit is "on".
Error LED
Illuminates Red if reverse polarity is detected. Blinks “on” and “off” when internal battery temperature is too high.
Charge LEDs
Indicates the charge level of the internal battery.
Boost LED
Illuminates White when Boost is active. LED flashes White when Manual Overide feature is active.
GB150
Buttons
Power Button
Push to turn unit "on" and "off".
Manual Override
To enable, push and hold for three (3) seconds. WARNING: Disables safety protection and manually forces Boost "On". Only for use when a battery is too low to be detected.
Light Mode
Toggles the ultra-bright LED light through 7 light modes: 100% > 50% > 10% > SOS > Blink > Strobe > Off
Voltmeter
The built-in voltmeter reads the voltage of the vehicle’s battery for enhanced diagnostics and troubleshooting.
Boost
TROUBLESHOOTING.
ERROR
REASON / SOLUTIONS
Error LED: Solid Red
Reverse polarity/Reverse the battery connections.
Error LED: Blinking Red w/Cables Connected Properly
The internal battery is too hot/ Allow the unit to cool. Bring the unit into cooler environment.
Boost Light Does Not Come On w/Cables Connected Properly
Connected battery is below 2-volts/ Remove all loads, and try again, or use Manual Override Mode.
GB150
MANUAL OVERRIDE
PUSH AND HOLD FOR 3 SECONDS.
WARNING: Disables safety protection and manually forces Boost “On”. Only for use when a battery voltage is too low to be detected.
Charge and Store.
GB150 Accessories
The GB150 is compatible with an array of NOCO accessories. Fast charge in your car with the GBC010 or at home with the XGC4. Store and protect your GB150 with the GBC015 EVA Case.
